Coloring the Mandelbulb

[reesej2]

I can't seem to make it go side-by-side... but I can turn my head just enough to make it work. Cool!

[trafassel]

Next time i combine both pictures in one bitmap. You can also use two webbrowsers side by side.

[kram1032]

The Ctrl - idea works but the text now is ridiculously small xD

[klixon]

The Ctrl - idea works but the text now is ridiculously small xD

Then you should press CTRL-0 (that's a zero) to reset the zoom-factor

[bib]

Stereo image

Cool!

[kram1032]

klixon: I know. I'd just like to read and see images at the same time

[trafassel]

Color distribution inside the mandelbulb.

<a href="http://www.youtube.com/v/j4_9rtHfDDU&rel=1&fs=1&hd=1" target="_blank">http://www.youtube.com/v/j4_9rtHfDDU&rel=1&fs=1&hd=1</a>

[trafassel]

Same coloring method, other fractal (formula 21 type).


The solution of a 2 coloring problem on a fractal map.

[kram1032]

it seems underexposured (dark) to me but it looks nice

[M Benesi]

I've been using the orbital color scheme since I discovered how to implement it in ChaosPro, and it's pretty nice.  I decided to mess around today, and changed the values I picked out of the iterations.

  First, I'm using what I call a "complex triplex" formula type.  It runs quite a bit faster than the trig versions, and I just threw in some further optimizations that shaved an extra second off of a small (444x444) zoomed in 10 iteration z^9 bulb.

  I was using the values r (the magnitude of x,y and z at the end of an iteration), x, y, and z to assign colors.  Well, I decided to simply take the components of the 2 complex numbers after I take them to the nth power, and ended up with a similar, but slightly more interesting color scheme (will put code after image):

z^3:

z^7 4d:

z^9:

Code:

r1=sqrt(sqr(sy)+sqr(sz));

			// this series for n=11, 13,15,16,17 shaves a bit of time off of calculations (halves time used)

			//I just found out that ChaosPro's compiler automatically does this for
			// certain powers: 2-10,12,14   so I rewrote the script to cover the powers (up to 17)
			// that it didn't aut0matically do it for

	if (n==11) {
		r3=sqr(sqr(sqr(r1)))*sqr(r1)*r1;
	} else if (n==13) {
		r3=sqr(sqr(sqr(r1)))*sqr(sqr(r1))*r1;
	} else if (n==15) {
		r3=sqr(sqr(sqr(r1)))*sqr(sqr(r1))*sqr(r1)*r1;
	} else if (n==16) {
		r3=sqr(sqr(sqr(sqr(r1))));
	} else if (n==17) {
		r3=sqr(sqr(sqr(sqr(r1))))*r1;
	}  else {
		r3=r1^n;
	}

	r3=r3^(-1);   //  instead of dividing by r3 below, I avoid division by zero errors by taking it to the -1 power here

	victor=complex(sx,r1);
	bravo=complex(sy,sz);

	if (n==11) {
		victor=sqr(sqr(sqr(victor)))*sqr(victor)*victor;
	} else if (n==13) {
		victor=sqr(sqr(sqr(victor)))*sqr(sqr(victor))*victor;
	} else if (n==15) {
		victor=sqr(sqr(sqr(victor)))*sqr(sqr(victor))*sqr(victor)*victor;
	} else if (n==16) {
		victor=sqr(sqr(sqr(sqr(victor))));
	} else if (n==17) {
		victor=sqr(sqr(sqr(sqr(victor))))*victor;
	}  else {
		victor=victor^n;
	}

	if (n==11) {
		bravo=sqr(sqr(sqr(bravo)))*sqr(bravo)*bravo;
	} else if (n==13) {
		bravo=sqr(sqr(sqr(bravo)))*sqr(sqr(bravo))*bravo;
	} else if (n==15) {
		bravo=sqr(sqr(sqr(bravo)))*sqr(sqr(bravo))*sqr(bravo)*bravo;
	} else if (n==16) {
		bravo=sqr(sqr(sqr(sqr(bravo))));
	} else if (n==17) {
		bravo=sqr(sqr(sqr(sqr(bravo))))*bravo;
	}  else {
		bravo=bravo^n;
	}

	nx=part_r(victor);
	ny=part_i(victor)*part_r(bravo)*r3;   // this is the part I would have divided by r3, it's better to multiply and never
	nz=part_i(victor)*part_i(bravo)*r3;  // get a division by zero error...

if (juliaMode) {
	sx=nx+cr;
	sy=ny+ci;
	sz=nz+cj;
} else {
	sx=nx+(pixelr);
	if (absmode) {
		sy=ny+(pixeli);
	} else {
		sy=ny+abs(pixeli);
	}
	sz=nz+(pixelj);
}
	if (rXmodeb) {
		z=quaternion(real(bravo),imag(bravo),real(victor),imag(victor));  // this is the new method, using components
  // before all math is applied to them (the addition of pixel components, plus multiplication by r3)
	} else if (rXmodec) {
		z=quaternion(sx,sy,sz,0);
		r=cabs(z);
		z=quaternion(r,sx,sy,sz);    // normal orbital coloring method
	} else {
		z=quaternion(sx,sy,sz,0);   // my initial mistake
	}
bail=abs(sx)+abs(sy)+abs(sz);

[kram1032]

as said in the other thread:
Great

[trafassel]

Stereo Images (cross eye).

[kram1032]

O.o
What a colourful danger for the eyes lol

[trafassel]

Same scene, higher iterations. Prostproduction is done with Paint.Net.

[trafassel]

Classic overlay coloring for all i
