Author Topic: Very hot Mandelbulb  (Read 4599 times)
Description: Mandelbulb with glow efect based on DE steps count
0 Members and 1 Guest are viewing this topic.
Buddhi
Fractal Iambus
***
Posts: 895



WWW
« on: January 01, 2010, 09:40:53 PM »
I'm testing now very simple method to add very nice glow to Mandelbulbs. This glow is completely for free because I use number of distance estimation steps. Pixel where ray goes nearly parallel to fractal surface needs much more steps to find fractal boundary (DE steps are smaller). When I set glow colour to red/yellow it looks like fire or very hot surfaces.

Below there are two renderings with this glow effect


http://www.fractalforums.com/gallery/?sa=view;id=1240


http://www.fractalforums.com/gallery/?sa=view;id=1255
Logged
My fractal gallery: http://krzysztofmarczak.deviantart.com
fractal animations: http://www.youtube.com/user/xlace
Mandelbulber program: https://github.com/buddhi1980/mandelbulber2
bib
Global Moderator
Fractal Senior
******
Posts: 2070


At the borders...


100008697663777 @bib993
WWW
« Reply #1 on: January 01, 2010, 09:51:11 PM »
hot!! cheesy
Logged
Between order and disorder reigns a delicious moment. (Paul Valéry)
cKleinhuis
Administrator
Fractal Senior
*******
Posts: 7044


formerly known as 'Trifox'


WWW
« Reply #2 on: January 01, 2010, 10:38:10 PM »
wow, cool effect cheesy
Logged
---

divide and conquer - iterate and rule - chaos is No random!
twinbee
Fractal Fertilizer
*****
Posts: 383



WWW
« Reply #3 on: January 02, 2010, 07:53:26 AM »
Lovely. I think I saw a small glow render of yours earlier too. Like to see you do something with that.
Logged
cbuchner1
Fractal Phenom
******
Posts: 443
« Reply #4 on: January 02, 2010, 05:24:22 PM »

Can you describe to us how you achieve the glow effect? This is very interesting, I would love to replicate that.
Logged
Buddhi
Fractal Iambus
***
Posts: 895



WWW
« Reply #5 on: January 02, 2010, 06:32:55 PM »
Quote from: cbuchner1 on January 02, 2010, 05:24:22 PM
Can you describe to us how you achieve the glow effect? This is very interesting, I would love to replicate that.

It is very simple when you are using Distance Estimation. You only have to count how many steps you need to find fractal surface or left rendering area. Glow intensity will be higher near fractal boundary because steps for finding fractal surface will be smaller and program has to calculate more steps. On attached drawing I tried to illustrate this effect. When you have number of steps you can use this value to make pixels brighter proportional to this value. But remember. It works only when program uses not constant steps but proportional to estimated distance. This glow effect don't make rendering slower because it needs only one simple counter.

* DE steps.png (28.12 KB, 438x443 - viewed 1250 times.)
Logged
My fractal gallery: http://krzysztofmarczak.deviantart.com
fractal animations: http://www.youtube.com/user/xlace
Mandelbulber program: https://github.com/buddhi1980/mandelbulber2
KRAFTWERK
Global Moderator
Fractal Senior
******
Posts: 1439


Virtual Surreality


WWW
« Reply #6 on: January 04, 2010, 04:07:23 PM »
Nice!

It´s -10 °C outside, this warms me!

J
Logged
Surreal Fractals http://mandelwerk.deviantart.com/
3Dprinted Fractals https://www.shapeways.com/shops/mandelpieces
